Ansible Vault Quick Start

Ansible Vault Quick Start

Vu Dao's photo
Vu Dao
·

3 min read

  • Ansible Vault encrypts variables and files so you can protect sensitive content such as passwords or keys rather than leaving it visible as plaintext in playbooks or roles.

  • 5 steps or less to quick start with ansible vault

1. Create password stored file to hold the master key

passwd_file

~: cat passwd_file
pLECtontABre

2. Generate encrypted password and data conent

  • Password for ssh-login

    $ ansible-vault encrypt_string --vault-id vagrant@passwd_file 'rootroot' --name vagrant
vagrant: !vault |
        $ANSIBLE_VAULT;1.2;AES256;vagrant
        33383365353665376338326665343364373334633265633438366263336638393937366661333430
        6662656233333563333461333962376539353634643563630a386335666632656435363863366339
        39623635363930373264636234653632616536343064313134623535653833353737313236313064
        6335323136366438640a373131373764393337303734386631303133336234343638623233356430
        3135
Encryption successful

  • Data encrypt

    ⚡ $ ansible-vault encrypt_string --vault-id dev@passwd_file 'my_credential_data' --name 'my_data_encrypted'
my_data_encrypted: !vault |
        $ANSIBLE_VAULT;1.2;AES256;dev
        65653537303030393632656639333262346565383266643734353865356163363538613736316465
        3734303334396561626538386466356461643035373166360a383735343735663234653736626565
        63363436626135373366633034353762623366333664633964666463373765396335373737313035
        3062393261613966360a373533326637323832633330303230383036636435383165376230656133
        31366231326330336137633035623763396533313735636531623438386632376536
Encryption successful

  • Update the encrypted things to var.yaml ``` vagrant: !vault |

        $ANSIBLE_VAULT;1.2;AES256;vagrant
    33383365353665376338326665343364373334633265633438366263336638393937366661333430
    6662656233333563333461333962376539353634643563630a386335666632656435363863366339
    39623635363930373264636234653632616536343064313134623535653833353737313236313064
    6335323136366438640a373131373764393337303734386631303133336234343638623233356430
    3135

my_data_encrypted: !vault | $ANSIBLE_VAULT;1.2;AES256;dev 65653537303030393632656639333262346565383266643734353865356163363538613736316465 3734303334396561626538386466356461643035373166360a383735343735663234653736626565 63363436626135373366633034353762623366333664633964666463373765396335373737313035 3062393261613966360a373533326637323832633330303230383036636435383165376230656133 31366231326330336137633035623763396533313735636531623438386632376536


### **3. Create ansible task to test decryption**
- [`test.yml`](https://github.com/vumdao/ansible-vault/blob/master/test.yml): Variable `my_data_encrypted` as encrypted value

⚡ $ cat test.yml

  • hosts: all become: true vars_files:
    • var.yaml tasks:
    • name: ansible vault test debug: msg: "{{ my_data_encrypted }}" ```
  • inventory: variable vagrant as the encrypted value ``` ⚡ $ cat inventory [ubuntu] 192.168.121.21

[all:vars] ansible_connection=ssh ansible_user=vagrant ansible_ssh_pass={{ vagrant }}


### **4. Run ansible-playbook**

⚡ $ ansible-playbook test.yml --vault-id dev@passwd_file -i inventory -e @var.yaml ok: [192.168.121.107]

< TASK [ansible vault test] >

    \   ^__^
     \  (oo)\_______
        (__)\       )\/\
            ||----w |
            ||     ||

ok: [192.168.121.107] => { "msg": "my_credential_data" }

< PLAY RECAP >

    \   ^__^
     \  (oo)\_______
        (__)\       )\/\
            ||----w |
            ||     ||

192.168.121.107 : ok=2 changed=0 unreachable=0 failed=0 skipped=0 rescued=0 ignored=0
```
