EC2 Spot Interruptions - AWS Fault Injection Simulator

Abstract

• AWS Fault Injection Simulator now supports Spot Interruptions, now you can trigger the interruption of an Amazon EC2 Spot Instance using AWS Fault Injection Simulator (FIS).

• With FIS, you can test the resiliency of your workload and validate that your application is reacting to the interruption notices that EC2 sends before terminating your instances.

• This blog guides you step-by-step to create FIS Experiment templates using AWS CDK

Table Of Contents

• Overview of EC2 spot instance

• Simulate Spot Interruptions architect

• Create Lambda function - send slack

• Create event rule of spot interruption

• Create FIS service role

• Create FIS Experiment Template

• Start experiment template

• Conclusion

---

🚀 Overview of EC2 spot instance

• Amazon EC2 Spot Instances reduce the cost up to 90% but can be interrupted or reclaimed at any time with a warning in 2 mins.

• We can use aws-node-termination-handler to ensure that the Kubernetes control plane responds appropriately to events that can cause your EC2 instance to become unavailable

🚀 Simulate Spot Interruptions architect

• Starting the FIS experiment which sends send-spot-instance-interruptions event.

• Use cloudwatch event rule to catch EC2 Spot Instance Interruption Warning event and then trigger lambda function for sending slack notifications.

• aws-node-termination-handler kubernetes DaemonSet also takes action when catching the event

---

Now we start creating CDK stacks

🚀 Create Lambda function - send slack

• Lambda handler parses the event to send a slack message which contains the event detail-type, instance ID and action

  app.py

  ```plaintext import requests from datetime import datetime import json

def send_slack(msg): """ Send payload to slack """ webhook_url = "https://hooks.slack.com/services/**" footer_icon = 'https://cdkworkshop.com/images/new-cdk-logo.png' color = '#36C5F0' level = ':white_check_mark: INFO :white_check_mark:' curr_time = datetime.now().strftime('%Y-%m-%d %H:%M:%S') payload = {"username": "Test", "attachments": [{ "pretext": level, "color": color, "text": f"{msg}", "footer": f"{curr_time}", "footer_icon": footer_icon}]} requests.post(webhook_url, data=json.dumps(payload), headers={'Content-Type': 'application/json'})

def handler(event, context): detail_type = event.get('detail-type', '') instance_id = event['detail']['instance-id'] action = event['detail']['instance-action'] message = f'{detail_type}\nresource: {instance_id}, action: {action}' send_slack(message)

* Lambda stack

    `lambda.ts`

    ```plaintext
    const send_slack = new lambda.Function(this, 'slackLambda', {
                description: 'Send Event message to slack',
                runtime: lambda.Runtime.PYTHON_3_8,
                code: lambda.Code.fromAsset('lambda-code/app.zip'),
                handler: 'app.handler',
                functionName: 'send-slack-spot-event'
            });

🚀 Create event rule of spot interruption

• The event listens to EC2 Spot Instance Interruption Warning to trigger the above lambda function

  event.ts

            const spot_event = new event.Rule(this, 'SpotEventRule', {
                description: 'Spot termination event rule',
                ruleName: 'spot-event',
                eventPattern: {
                    source: ['aws.ec2'],
                    detailType: ['EC2 Spot Instance Interruption Warning'],
                    detail: {
                        'instance-action': ['terminate']
                    }
                }
            });

            spot_event.addTarget(new event_target.LambdaFunction(send_slack));


🚀 Create FIS service role

• IAM role for AWS FIS permissions to handle the target resources here is EC2 instance

  fis_role.ts

            const fis_role = new iam.Role(this, 'FisRole', {
                roleName: 'spot-fis-test',
                assumedBy: new iam.ServicePrincipal('fis.amazonaws.com')
            });

            const ec2_policy_sts = new iam.PolicyStatement({
                sid: 'SpotFisTest',
                effect: iam.Effect.ALLOW,
                actions: [
                    'ec2:DescribeInstances',
                    'ec2:StopInstances',
                    'ec2:SendSpotInstanceInterruptions'
                ],
                resources: ['arn:aws:ec2:ap-northeast-1:*:instance/*'],
                conditions: {
                    'StringEquals': {'aws:RequestedRegion': props?.env?.region}
                }
            });

            fis_role.addToPolicy(ec2_policy_sts);


🚀 Create FIS Experiment Template

• The experiment template includes:

  • Action: send-spot-instance-interruptions, parameter: durationBeforeInterruption PT2M

  • Targets:

    • Resource type: aws:ec2:spot-instance

    • Resource filters: State.Name=running

    • Selection mode: COUNT(1)

• Stack

  fis.ts

            const target: fis.CfnExperimentTemplate.ExperimentTemplateTargetProperty = {
                resourceType: 'aws:ec2:spot-instance',
                resourceTags: {'eks:nodegroup-name': 'eks-airflow-nodegroup-pet'},
                selectionMode: 'COUNT(1)',
                filters: [{
                    path: 'State.Name',
                    values: ['running']
                }]
            };

            const action: fis.CfnExperimentTemplate.ExperimentTemplateActionProperty = {
                actionId: 'aws:ec2:send-spot-instance-interruptions',
                parameters: {'durationBeforeInterruption': 'PT2M'},
                targets: {'SpotInstances': 'spot-fis-target'}
            };

            const fis_exp = new fis.CfnExperimentTemplate(this, 'FisExperiment', {
                description: 'Spot Interruption Simulate',
                roleArn: fis_role.roleArn,
                tags: {
                    'Name': 'spot-interrupt-test',
                    'cdk': 'fis-stack'
                },
                stopConditions: [
                    {source: 'none'}
                ],
                targets: {'spot-fis-target': target},
                actions: {'send-spot-instance-interruptions': action}
            });


🚀 Start experiment template

• Start

• Complete

• Slack notify the event and aws-node-termination-handler action either

🚀 Conclusion

• This kind of FIS experiment helps us to test the scenario of spot interruption to check aws-node-termination-handler and fault tolerance of the application

• We should also know about FIS pricing. The AWS FIS price is $0.10 per action-minute.
