EKS Cluster CONSOLE CREDENTIALS

OOPS!!! "error: You must be logged in to the server (Unauthorized)" - If you get this error when trying to run kubectl commands, Read more ⤵️⤵️⤵️

- When an Amazon EKS cluster is created, the IAM entity (user or role) that creates the cluster is added to the Kubernetes RBAC authorization table as the administrator (with system:masters permissions). Initially, only that IAM user can make calls to the Kubernetes API server using kubectl. So ensure that your console such as EC2 instance attached that user/role credential for further steps, otherwise, no way to use the kubectl.

- In this tutorial, we will introduce how to create an IAM entity that having the system:master permissions on the existing EKS cluster, attaching this role to an EC2 instance and accessing to EKS cluster via kubectl installed on this instance.

What’s In This Document

• Authentication and authorization in Amazon EKS

• Check aws-auth ConfigMap to see which role is bind with the cluster

• Check the AWS credentials for an IAM role that's attached to an instance

• Create kubeconfig file to access EKS cluster

• Allowing a user/role or instance profile call API to EKS cluster

• Conclusion

---

Pre-Requisite:

• EKS cluster

• IAM fully access

---

🚀 Authentication and authorization in Amazon EKS

• Explain in a simple way, when you make an API call to EKS cluster through kubectl, a token is generated using the IAM credentials that are returned with the aws sts get-caller-identity command

• Amazon EKS uses that token authentication webhook to authenticate the request but it still relies on native Kubernetes RBAC for authorization.

• The crux of this integration between IAM and RBAC is the aws-auth ConfigMap applied to the Amazon EKS cluster that provides the mappings between IAM principals (roles/users) and Kubernetes Subjects (Users/Groups).

• Ref: https://aws.amazon.com/blogs/containers/kubernetes-rbac-and-iam-integration-in-amazon-eks-using-a-java-based-kubernetes-operator/

🚀 Check aws-auth ConfigMap to see which role is bind with the cluster

• Following command will show that the role role/eks-admin-role with proper IAM permissions is added to the Kubernetes RBAC authorization table as the administrator (with system:masters permissions).

[ec2-user@eks-ctl ~]$ kubectl describe configmap -n kube-system aws-auth
Name:         aws-auth
Namespace:    kube-system
Labels:       aws.cdk.eks/prune-c8c49db9cb02222a1111111db00d4db8236bxxxxxx=
Annotations:  kubectl.kubernetes.io/last-applied-configuration:
                {"apiVersion":"v1","data":{"mapAccounts":"[]","mapRoles":"[{\"rolearn\":\"arn:aws:iam::123456789012:role/eks-admin-role\",\"username\":\"

Data
====
mapAccounts:
----
[]
mapRoles:
----
[{"rolearn":"arn:aws:iam::123456789012:role/eks-admin-role","username":"arn:aws:iam::123456789012:role/eks-admin-role","groups":["system:masters"]},{"rolearn":"arn:aws:iam::123456789012:role/eks-worker-role","username":"system:node:{{EC2PrivateDNSName}}","groups":["system:bootstrappers","system:nodes"]}]
mapUsers:
----
[]
Events:  <none>

• Now, if you have permission to attach that role to the EC2 instance or AWS cloud9, move to next step to create kubeConfig file

🚀 Create kubeconfig file to access EKS cluster

• What is Kubeconfig File - A kubeconfig file is a file used to configure access to Kubernetes when used in conjunction with the kubectl commandline tool (or other clients).

• How to generate kubeconfig file?

[ec2-user@eks-ctl ~]$ aws eks update-kubeconfig --name eks-cluster --region ap-northeast-2
Added new context arn:aws:eks:ap-northeast-2:123456789012:cluster/eks-cluster to /home/ec2-user/.kube/config

• Check content of the file /home/ec2-user/.kube/config (or use command kubectl config view --minify) and notice at the exec args. When you use kubectl to interact with Amazon EKS under the hood it uses the aws eks get-token command to fetch an authentication token, which is passed along in the Authorization header of an HTTP request sent to the Kubernetes API server.

[ec2-user@eks-ctl ~]$ kubectl config view --minify
apiVersion: v1
clusters:
- cluster:
    certificate-authority-data: DATA+OMITTED
    server: <API server endpoint>
  name: arn:aws:eks:ap-northeast-2:123456789012:cluster/eks-cluster
contexts:
- context:
    cluster: arn:aws:eks:ap-northeast-2:123456789012:cluster/eks-cluster
    user: arn:aws:eks:ap-northeast-2:123456789012:cluster/eks-cluster
  name: arn:aws:eks:ap-northeast-2:123456789012:cluster/eks-cluster
current-context: arn:aws:eks:ap-northeast-2:123456789012:cluster/eks-cluster
kind: Config
preferences: {}
users:
- name: arn:aws:eks:ap-northeast-2:123456789012:cluster/eks-cluster
  user:
    exec:
      apiVersion: client.authentication.k8s.io/v1alpha1
      args:
      - --region
      - ap-northeast-2
      - eks
      - get-token
      - --cluster-name
      - eks-cluster
      command: aws
      env: null

🚀 Allowing a user/role or instance profile call API to EKS cluster

- To check the AWS credentials for an IAM role that's attached to an instance, run following command

[ec2-user@eks-ctl ~]$ curl http://169.254.169.254/latest/meta-data/iam/security-credentials/eks-admin-role
{
  "Code" : "Success",
  "LastUpdated" : "2021-06-12T06:23:32Z",
  "Type" : "AWS-HMAC",
  "AccessKeyId" : "<AWS_ACCESS_KEY>",
  "SecretAccessKey" : "<AWS_SECRET_KEY>",
  "Token" : "<THE_TOKEN",
  "Expiration" : "2021-06-12T12:38:22Z"
}

• Note: If running the preceding curl command returns a 404 error, check the following:

$ export NO_PROXY=169.254.169.254

- If you have full IAM access you can add more usre/role to access the EKS cluster by updating the aws-auth ConfigMap

• Run kubectl edit configmap aws-auth -n kube-system

  • Add the IAM user to mapUsers here is eks-test user (no need to add any permission for this user)

    mapUsers: |
      - userarn: arn:aws:iam::123456789012:user/eks-test
        username: eks-test
        groups:
          - system:masters

• Add the IAM role to mapRoles

    mapRoles: | - rolearn: arn:aws:iam::123456789012:role/testrole username: testrole groups: - system:masters

- Then update kubeConfig file again with that role or user

• For adding role

aws eks update-kubeconfig --name eks-cluster-name --region aws-region --role-arn arn:aws:iam::123456789012:role/testrole

• For adding user, no more option but need to update kubeConfile for using --profile eks-test (you need to create this profile with AWS key and credential of that user)

•   aws eks update-kubeconfig --name eks-cluster-name --region aws-region


user:
      exec:
        apiVersion: client.authentication.k8s.io/v1alpha1
        args:
        - --region
        - ap-northeast-2
        - eks
        - get-token
        - --cluster-name
        - eks-cluster
        - --profile
        - eks-test
        command: aws

- Verify

 $ kubectl get node
NAME                                          STATUS   ROLES    AGE     VERSION
ip-10-0-0-0.ap-northeast-2.compute.internal   Ready    <none>   2d22h   v1.19.6-eks-49a6c0

🚀 Conclusion

• Setting up the console credential to control EKS cluster using cloud9 or EC2 (directly) is optional since mostly use CLI-driven

• But, if you’d like full access to your EKS cluster in the EKS console it is recommended.

---
